Features
Connect your PCX Hybrid panel to the Enforcer two-way wireless security devices, giving you a truly hybrid system.
The award-winning Enforcer two-way wireless technology gives you the flexibility of a wireless device with the reliability and stability of wired security detectors and sensors.
Instant two-way Device Control (ITDC)
The ITDC technology enables instant wake-up and instant sleep of each device on the system, allowing continuous communication between the control panel and wireless devices while preserving battery power. This technology not only provides installers with total control of each device, but also gives users peace of mind that they have a reliable and secure wireless system.
Ensuring that all wireless detection devices know when the system is armed and disarmed.
Ensuring that they are awake as soon as the system is armed.
Two-way Wireless Technology
Each wireless device on the Enforcer system, including movement detectors is a transmitter and a receiver. The wireless technology used on the Enforcer system holds a significant advantage over one way and some two way wireless products currently available on the market
Signal Strength Indicator (SSI)
One of the key advantages of implementing of the SSI technology is to allow the installer to view the wireless transmission signal strength on both the control panel and wireless devices in real time.
Pyronix High Security Wireless Protocol Encryption
The two-way wireless protocol has been developed by Pyronix to ensure that the communication between all wireless system components is protected on a very high security level. The protocol uses the 128 bit Pyronix advanced encryption.
Technical Specifications
Input and output expanders technical characteristics
Plastic housingYes
Tamper protectionFront and rear
Enforcer two-way wireless technology
Instant two way device control (ITDC)Yes
Pyronix high security two way wireless data encryption protocol (TDE)Yes
Pyronix intelligent jamming detectionYes
Programmable wireless supervision timeYes
868MHz transceiver FM technologyYes
Tranmission methodFully encrypted rolling code
Transmission range1.6 km in open space
Inputs & outputs
Two-way wireless inputs32
Two-way wireless keyfobs32
Two-way wireless sirens2
Environmental and operating features
Storage temperature-40°C to +80°C
Certified operating temperature-10°C to +50°C
Nominal operating temperature-10 to +50°C
Physical dimensions (H x W x D)173 x 125 x 32mm
Electrical & battery
Operating voltage9V – 15V
Quiescent current consumption60mA
Certifications and warranty
Electrical conformityCE
EN CertificateEN50131-1:2006+A1:2009
EN50131-3:2009
EN50131-6:2008
EN50131-5-3:2005+A1:2008
Certification typeIMQ
Certificate numberCA12.01439
Environmental classII
Warranty2 years
Security GradeGrade 2
